8.5 Output
Configurable bit number
(only BTL7-S510(B)-…)
16-32
Coding Binary or Gray
Characteristic Rising or falling
SSI data Position, speed, absolute
speed, differential position,
speed difference (between
2magnets), error value
SSI clock frequency f
Clk
10kHz…1MHz
Behavior at null point BTL7 standard:
No negative values between
flange and null point
BTL7-S510(B)-…:
Configurable
Short-circuit protection Signal lines Data+/−, Clk+/−
to +36V or GND
8.6 Dimensions, weights
Rod diameter 8mm or 10.2mm
Nominal length
For Ø8mm 25…1016mm
For Ø10.2mm 25…7620mm
Weight (depends on
length)
Approx. 2kg/m
Housing material Aluminum
Flange material Stainless steel
Rod material Stainless steel
Rod wall thickness
For Ø8mm 0.9mm
For Ø10.2mm 2mm
Young's modulus Approx. 200kN/mm
2
Housing mounting via
threads
M18×1.5 or 3/4"-16UNF
Tightening torque Max.100Nm
8
Technical data (continued)
BTL7-…-KA__
Cable material PUR
cULus20549
80 °C, 300V,
internal wiring
Cable temperature –40°C…+90°C
Cable diameter Max. 7mm
Permissible bending
radius
Fixed routing ≥35mm
Movable ≥105mm
BTL7-…-FA__
Cable material PTFE
No UL approval available
Cable temperature –55°C…+200°C
Cable diameter Max. 7mm
Permissible bending
radius
Fixed routing ≥35mm
Movable No permissible bending
radius
BTL7-S5 __ (B)-M ____ -A/B/Y/Z(8)-S32/S115/S140/S147/KA __ /FA __
Micropulse Transducer - Rod Style
