Balluff BTL7-S5 B-M Series User Manual

24 english
10
Type code breakdown
BTL7 standard
BTL7 - S 5 0 1 B - M0500 - B - S32
Micropulse transducer
SSI interface
Supply voltage:
5 = 10…30VDC
Data format:
24bit 25bit 26bit
0 = Binary, rising 6 = Binary, rising A = Binary, rising
1 = Gray, rising 7 = Gray, rising B = Gray, rising
2 = Binary, falling 8 = Binary, falling C = Binary, falling
3 = Gray, falling 9 = Gray, falling D = Gray, falling
Resolution:
1 = 1µm 3 = 10µm 5 = 40µm 7 = 2µm
2 = 5µm 4 = 20µm 6 = 100µm 8 = 50µm
Synchronous/asynchronous operation:
B = synchronous operation
without B = asynchronous operation
Nominal length (4-digit):
M0500 = Metric specification in mm, nominal length 500mm
(M0025…M1016: A8, B8, Y8, Z8)
(M0025…M7620: A, B, Y, Z)
Rod version, fastening:
A = Metric mounting thread M18x1.5, O-ring, rod diameter 10.2mm
B = Metric mounting thread M18x1.5, O-ring, rod diameter 10.2mm
Y = 3/4"-16UNF thread, O-ring, rod diameter 10.2mm
Z = 3/4"-16UNF thread, O-ring, rod diameter 10.2mm
A8 = Metric mounting thread M18x1.5, O-ring, rod diameter 8mm
B8 = Metric mounting thread M18x1.5, O-ring, rod diameter 8mm
Y8 = 3/4"-16UNF thread, O-ring, rod diameter 8mm
Z8 = 3/4"-16UNF thread, O-ring, rod diameter 8mm
Electrical connection:
S32 = 8-pin, M16 plug per IEC130-9
S115 = 8-pin, M12 plug
S140 = 10-pin, plug
S147 = 7-pin, M16 plug acc. to DIN45329
KA05 = Cable, 5m (PUR)
FA05 = Cable, 5m (PTFE)
BTL7-S5 __ (B)-M ____ -A/B/Y/Z(8)-S32/S115/S140/S147/KA __ /FA __
Micropulse Transducer - Rod Style
