Balluff BTL7-S5 B-M Series User Manual

www.balluff.com 5english
1.1 Scope
This guide describes the construction, function and setup
options for the BTL7 Micropulse Transducer with SSI
interface. It applies to types
BTL7-S5 __ (B)-M ____ -A/B/Y/Z(8)-S32/S115/S140/
S147/KA
__ /FA __ (see Type code breakdown on
page24 or page25).
The guide is intended for qualified technical personnel.
Read this guide before installing and operating the
transducer.
1.2 Symbols and conventions
Individual instructions are indicated by a preceding
triangle.
► Instruction 1
Action sequences are numbered consecutively:
1. Instruction 1
2. Instruction 2
Note, tip
This symbol indicates general notes.
1.3 Scope of delivery
– BTL7 transducer
– Condensed guide
The magnets are available in various models
and must be ordered separately.
1.4 Approvals and markings
UL approval
1)
File no.
E227256
US Patent 5923164
The US patent was awarded in connection with this
product.
1)
Not for BTL7-…-FA__
The CE Mark verifies that our products
meet the requirements of the current
EMC Directive.
The transducer meets the requirements of the following
product standard:
– EN61326-2-3 (noise immunity and emission)
Emission tests:
– RF emission
EN55011
Noise immunity tests:
– Static electricity (ESD)
EN 61000-4-2
Severity level 3
– Electromagnetic fields (RFI)
EN 61000-4-3
Severity level 3
– Electrical fast transients (burst)
EN 61000-4-4
Severity level 3
– Surge
EN 61000-4-5
Severity level 2
– Conducted interference induced
by high-frequency fields
EN 61000-4-6
Severity level 3
– Magnetic fields
EN 61000-4-8
Severity level 4
More detailed information on the guidelines,
approvals, and standards is included in the
declaration of conformity.
1.5 Abbreviations
SSI Synchronous Serial Interface
1
Notes to the user
BTL7-S5 __ (B)-M ____ -A/B/Y/Z(8)-S32/S115/S140/S147/KA __ /FA __
Micropulse Transducer - Rod Style
