Specifications
2. Specifications
2.1 Emitter and Receiver Specifications
Emitter/Receiver Range
9.5 mm (3/8") Beam Spacing
0.6to6.1m(2to20')forsensors<4'
0.6to4.6m(2to15')forsensors>4'
NOTE:Maximumrangeisspecifiedatthe
pointwhere3xexcessgainremains.
19.1 mm (3/4") Beam Spacing
0.9to17m(3to55')forsensors<4'
0.9to14m(3to45')forsensors>4'
NOTE:Maximumrangeisspecifiedatthepoint
where3xexcessgainremains.
Minimum Object Sensitivity
9.5 mm (3/8") Beam Spacing
19.1mm(0.75")
InterlacedMode:12.7mm(0.5")*
*NOTE:Assumessensingisinmiddle
one-thirdofscanningrange.
19.1 mm (3/4") Beam Spacing
38.1mm(1.5")
InterlacedMode:25.4mm(1.0")*
*NOTE:Assumessensingisinmiddle
one-thirdofscanningrange.
Sensor Scan Time
55microsecondsperbeam,plus1millisecondprocessingtimeperscan.(Assumesstraightscan,
continuousscan,andTBB mode;seeSection5.5.5ScanningModesforfurtherinformation.)
Power Requirements
Emitter
0.10amps@12Vdc
NOTE:Maximumcurrentisfora6'sensor.
Receiver
9.5mm(3/8")beams:0.75amps@12Vdcmax.
19.1mm(3/4")beams:0.50amps@12Vdcmax.
NOTE:Maximumcurrentisfora6'sensor.
Connections
Emitterandreceiverconnecttocontrollerusingtwo5-conductorquick-disconnectcables(one
eachforemitterandreceiver),orderedseparately.SeeSection1foravailablecablelengths.
Cablesmeasure8.1mm(0.32")dia.,andareshieldedandPVC-jacketed;conductorsare20-gauge.
•UseonlyBannercables,whichincorporatea"“twistedpair”fornoiseimmunityonRS-485data
communicationlines.
•Emitterandreceivercablesmaynotexceed250'each.
Status Indicators
(See Section 6.1 for more
information)
Emitter
RedLEDlightsforproperoperation
Receiver
Green:sensorsaligned(>3xexcessgain)
Yellow:marginalalignment(1x-3xexcessgain)
Red:sensorsmisalignedorbeam(s)blocked
Environmental Rating
NEMA4,13(IECIP65)
Construction
Aluminumhousingwithblackanodizedfinish;acryliclenscover
Operating Conditions
Temperature:
 -20°to70°C(-4°to158°F)
Max. rel. humidity:
95%(non-condensing)
