Conversion can only be performed by an authorised person. Installation
can only be performed by a licensed gas fitter, a compliance certificate
must be issued. For Range units, follow the conversion instructions
supplied separately with that unit.
12.Using two spanners, remove the LPG hose and regulator assembly, and attach the
NG gas connection. Note that the manifold connections are ½” BSP fittings. If your
gasfitter is connecting direct to the gas supply with appropriate fittings not using a
bayonet, then a NG Regulator (RCV250Q) must be fitted to each appliance. For
bayonet connections, use separately supplied NGCK250VJQ which includes NG
governor.
13.Affix the NATURAL GAS label to the Barbeque and any side burners in place
of the previous UNIVERSAL LPG label. Check that all new injectors match the
compliance plate data. Conduct a full leak test. Conduct a pressure check test with
half the burners in use. Conduct a performance test in particular to check the low
flame settings on the main burners and adjust where necessary so that the flames
do not blow out too easily on low settings. Ensure the owner / users are aware of the
new gas type and how to operate the appliance. Check the installation meets
S5601 and issue a com
liance certificate to the owner.
14.Reinstall the flame tamers,
ceramic tiles and racks,
cooking grills and hotplates.
Converting from LPG to NG (continued)
BROMIC MF15 (1/2”) Female x Male BSP
Connections
GA certificate 7425
BROMIC SS hose assembly 13mm ID 1500
mm AGA certificate 5497
BROMIC, Model No. 980L NG Governor
AGA certificate 5862
Type 1 connector (Bayonet connector)
BROMIC SS hose assembly 13mm ID 300 mm
AGA certificate 5497
