Page 44
10.Replace the side
burner. Make
sure that the side
burner is properly
engaged onto the
valve as shown.
11.a. Take off the side burner control knob.
b. Locate the side burner low flame screw and adjust for NG by turning it:
SS side burner: anticlockwise two full turns (720°).
(For reference, the LPG low flame position is 120° anticlockwise from the clockwise
full stop position. The NG low flame position is 840° anticlockwise from the clockwise
full stop position.)
CI side burner: anticlockwise two full turns (720°).
(For reference, the LPG low flame position is 210° anticlockwise from the clockwise
full stop position. The NG low flame position is 930° anticlockwise from the clockwise
full stop position.)
c. Replace the side burner control knob.
MCDXBSBSHELFV CI Side Burner
MCBSBSHELFV SS Side Burner
a
c
b
Converting from LPG to NG (continued)
