Page 43
6. Using two spanners, one
to hold the fitting, the
other to turn the nut,
loosen and disconnect
the locking nut that fixes
the rear burner injector in
place. Unscrew the LPG
injector (stamped 0.93)
anticlockwise and replace
with the NG injector
(stamped 1.54). Using
two spanners, replace
and tighten the locknut.
7. Leak test the rear burner
connections before
replacing the rear burner
cover. Refer to the Safety
Leak Testing guide in this
manual.
8. Where a side burner is fitted, open
the lid and remove the trivet. Undo
the screws holding the burner in
place. Take care for the CI burner
not to drop it once the support
bracket is loosened.
9. Use a socket spanner to remove the LPG
(stamped 0.96 for SS; stamped 1.24 for CI)
side burner injector by turning it
anticlockwise.
Replace the LPG injector with an NG
injector (stamped1.61 for SS; stamped 2.04
for CI) tighten clockwise with the socket
spanner, DO NOT overtighten.
1
2
Converting from LPG to NG (continued)
