ImagePRO-II • User’s Guide 95
4. Menu Orientation
Using the Tech Support Menu
~ Fill H/V fills the entire active area with the scaled image.
~ Zoom H zooms in or out on the horizontal center of the image.
Increasing this setting “stretches” the image to the right and left along the
horizontal plane. Decreasing this setting brings the right and left edges in
toward the center of the active area.
~ Zoom V zooms in or out on the vertical center of the image. Increasing
this setting “stretches” the image up and down along the vertical plane.
Decreasing this setting brings the top and bottom edges in toward the
center of the active area.
~ Zoom H/V zooms in or out both horizontally and vertically.
~ Pan H moves the image to the right or left on the wall.
~ Pan V moves the image up or down on the wall.
~ Units applies to the Pan and Zoom settings. The choices are Pixel and
Percent. The default setting is Pixel.
~ Save View provides the opportunity to save your settings. You can save
one view for each input. When you select this option, a prompt appears.
Press SEL to save the view or ESC to cancel.
~ Recall View restores the last saved view.
~ Reset restores the default settings.
For additional information about creating and saving views, refer to Creating a
View on page 71 of this chapter.
• Selecting Save Snapshot saves the following settings:
~ All System Menu changes
~ All Output Menu changes
~ All Input Menu changes for all input channels
rëáåÖ=íÜÉ=qÉÅÜ=pìééçêí=jÉåì
The Tech Support Menu, shown in the following illustration, provides quick access to
Customer Support contact information, and also shows you the software version for your
ImagePRO-II.
Figure 4-86. Tech Support Menu
This menu displays:
• The software version your ImagePRO-II uses. This number changes when you
update system software. Refer to Appendix C, Upgrading Firmware,
on
page 167 for software upgrade instructions.
TECH SUPPORT
Version 1.00
Phone 866-374-7878
www.barco.com/esupport
