2. Hardware Orientation
ImagePRO-II Front Panel
8) FRZ Button
FRZ (FREEZE) enables you to freeze a displayed image. Refer to The FRZ
Button on page 11 for more information.
qÜÉ=aáëéä~ó=pÉÅíáçå
The Display Section consists of a 4-line x 24-character screen that shows all
ImagePRO-II menus, sub-menus, and messages. The display is dimmable.
At system startup, or when no menu buttons are selected, the screen displays the Status
Menu. The following illustration shows a sample Status Menu in the display screen.
Figure 2-2. Status Menu (sample)
This menu provides information about the selected input, including:
• Line 1 — The input video format in the form H active x V active @ Vertical
refresh rate (i.e., 1280 x 1024@60 Hz). If a custom configuration file is associated
to the selected input, the name of the file appears on the display.
• Line 2 — Genlock and input signal type including:
~ The current status of Genlock for the output channel:
• EXT — Lock to external
• IN# — Lock to input number n
• N/A —Freerun (Default)
~ The type of input signal being processed. Input signal types are:
CVBS, Y/C, SDI, RGB, YP
b
P
r
, DVI, HDMI, SDI, and DP.
• Line 3 — The output video format in the form Hact x Vact @ vr Hz (i.e.,
1920x1080i @ 59.94 Hz).
qÜÉ=jÉåì=k~îáÖ~íáçå=pÉÅíáçå
The Menu Navigation Section includes three controls that aid in menu navigation:
• Turn the ADJUST knob to scroll through the menu items on the screen.
~ Turn the knob counter-clockwise to scroll down.
~ Turn the knob clockwise to scroll up.
A navigation cursor (>) to the left of a menu item indicates the position of the
scroll bar, as shown in the following illustration.
IN: 1280x1024p @59.94
Genlock: N/A DVI
CHA: 1920x1080p @60
To Next Page
