4. Menu Orientation
Configuring Inputs
fåéìí=jÉåì=cìåÅíáçåë=~åÇ=pìÄãÉåìë
The following Input Menu functions and submenus are covered in this section:
Setting the Input Format
Adjusting Edge Timings
Selecting the Input Type Setting Input Contrast and Brightness
Selecting the Colorspace Setting Input Color Balance
Using 1:1 Sample Adjusting Gamma
Setting the Aspect Ratio Processing Interlaced and Film Signals
Sizing an Image About Input Configurations
Adjusting Timing Parameters
pÉííáåÖ=íÜÉ=fåéìí=cçêã~í
The input video Format is indicated in the status display and in the Input Menu, in the form
HactxVact @ vr Hz:
 Example: 1024x768 @ 75 Hz
When In Auto Acquire is On, the input video format is detected in the following search
order: last used configuration, any saved configurations, custom library formats, standard
library formats, or a “best guess” based on the closest video format in the library.
If the video format is a best guess, it is displayed within asterisks:
 Example: *1024x768 @ 60.11*
If the video format is recalled from a saved input configuration, the format appears with a
“c” at the far right:
 Example: 1024x768 @ 59.94 c
When In Auto Acquire is Off, the ImagePRO-II attempts to lock to the signal you select. If
the format you select does not match the input signal, the display remains black and the
status display indicates Invalid Signal.
For more information about In Auto Acquire, refer to the Acquiring an Input Signal
section on page 64.
pÉäÉÅíáåÖ=íÜÉ=fåéìí=qóéÉ
Input Type defines the type of input connected to the ImagePRO-II, such as RGB, DVI-I, or
HDMI.
First, select an input. Then, from the Input Menu, scroll to Type and select a value.
Available choices depend on the input you select:
• For Input 1 (DVI-I), the options are RGB, YP
b
P
r
, YC, CVBS, DVI-I.
• For Input 2 (HD-15), the options are RGB, YP
b
P
r
, YC, CVBS.
• For Input 3 (HDMI), the option is HDMI.
• For Input 4 (DisplayPort), the option is DP.
• For Input 5 (SDI-1), the option is SDI.
