4 ImagePRO-II • User’s Guide
NK==fåíêçÇìÅíáçå
ImagePRO-II Overview
fã~ÖÉmolJff=lîÉêîáÉï
The following topics are discussed in this section:
• ImagePRO-II Universal Video Processor
• ImagePRO-II Features
• Control Overview
fã~ÖÉmolJff=råáîÉêë~ä=sáÇÉç=mêçÅÉëëçê
The ImagePRO-II
TM
is a high-performance all-in-one video scaler, scan converter, switcher
and transcoder. The ImagePRO-II converts a wide range of user-selectable video input
signals — including RGB, HDTV, DisplayPort, HDMI
™
, component, S-video, composite
(NTSC, PAL) and HD/SDI — into an impressive array of output signal formats, to meet the
requirements of virtually any application. Using the ImagePRO-II, you can scale video
sources while maintaining a high quality image. The ImagePRO-II supports resolutions up
to WQXGA (2560x1600) @ 60 Hz.
The ImagePRO-II supports DisplayPort and HDMI signal formats, while still supporting
DVI, SDI, and analog signals.
The ImagePRO-II also supports High-Bandwidth Digital Content Protection (HDCP) on
its DVI, HDMI, and DisplayPort connectors.
You can operate the ImagePRO-II using convenient front-panel controls to activate inputs,
navigate through the menu system, quickly access key menus, freeze the video, and
transition to a logo or internal black. A front-panel USB port is provided for downloading
and restoring logo images and system configurations.
Using the ImagePRO-II Web Interface, you also can remotely control all ImagePRO-II
features from a computer, tablet, smartphone, or other web-enabled mobile device. With
the Web Interface’s easy-to-use pages, menus and graphics, you can, for example,
upgrade system firmware, run test patterns, and control inputs and outputs. For more
information about the Web Interface, refer to Chapter 5, Web Remote Control
Operations, on page 99.
You can also operate the ImagePRO-II remotely using the Barco Encore
™
Controller
(release 2.32 or higher), or the ScreenPRO-II
™
Controller.
fã~ÖÉmolJff=cÉ~íìêÉë
The ImagePRO-II provides the following features:
• System capabilities:
~ High-resolution Athena scaler
~ Transitions through black or a logo
~ 1 RU chassis
~ SD, HD, and 3Gbit SDI I/O
~ Dual-link DVI/HDCP I/O
~ HDMI/HDCP I/O
~ DisplayPort/HDCP I/O
~ Loop-through on DVI, HD-15, and SDI inputs
