ImagePRO-II • User’s Guide 35
4. Menu Orientation
Configuring Inputs
As you change the input Type, the default Colorspace setting changes, too. For example,
if you select YP
b
P
r
or YC, the Colorspace changes to SMPTE. If you select RGB, the
Colorspace changes to RGB. For details about these options, refer to Selecting the
Colorspace on this page.
When you auto-acquire a signal, type selections are limited depending on the input
selected. For example, if Input 3 is connected to an HDMI source, HDMI is the only option
for that input and cannot be changed.
When you are not auto-acquiring a signal, you can choose a type for the selected input. If
you choose a type that is not applicable to the input, the Status Menu displays the Invalid
Signal message. For information about auto acquisition, refer to Acquiring an Input
Signal on page 64.
pÉäÉÅíáåÖ=íÜÉ=`çäçêëé~ÅÉ
The Colorspace defines the Composite Video Standard for an input. The options available
depend on the selected input and the input Type, as shown in the following table.
Table 4-2. Input Colorspace Chart
Input Input Type Colorspace Options
1 (DVI-I — Digital) DVI RGB
1 (DVI-I — Analog) CVBS SMPTE
RGB RGB
Y/C SMPTE
YP
b
P
r
SMPTE
2 (HD-15) CVBS SMPTE
RGB RGB or SMPTE
Y/C SMPTE
YP
b
P
r
SMPTE or RGB
3 (HDMI) HDMI RGB or YCbCr
4 (DisplayPort) DP RGB or YCbCr
5 (SDI-1) SDI SMPTE
