156 ImagePRO-II • User’s Guide
B. Remote Control Protocol
ImagePRO-II Remote Commands
• Query Response: System Manager Settings in the following format
SYSMGR --blkinv (Black Invalid Mode) --vfd (VFD
Brightness) --conmode (Encore Connect Mode) --unitid
(Encore Unit ID) --encoreip (Encore IP Address)
sfa`li
• Description: Video Color Settings for Input/Output
• Required parameters:
--con (connector), for input video color
--och (output channel), for output video color
--itype (input type), for commands to DVI input settings
• Parameters:
--con (connector): 0-4
0 = DVI, 1 = HD15, 2 = HDMI, 3 = DP, 4 = SDI1
--och (output channel): 0-1
--itype (input type): 0 = digital, 1 = analog
--brt (overall brightness): [50..150]
--cbrt (individual brightness): [50..150]
--cnt (overall contrast): [50..150]
--ccnt (individual contrast): [50..150]
--col (color) (must be supplied for --cbrt or --ccnt parameters):
0 = all color, 1 = red, 2 = green, 3 = blue
--sat (saturation): [0..125]
--hue (hue): [-90..90]
--cinv (color invert): 0 = Normal, 1 = Inverted Color
--csp (colorspace): 0 = RGB, 1 = YUV
--gamma (gamma): 0.3 - 3.0
--mono (monochrome): 0 = Normal, 1 = Monochrome
• Query Format 1 (Input):
VIDCOL --con (connector) --?
• Query Response 1: Video Color Settings in the following format:
VIDCOL --brt (ovr bright) --cbrt (R bright) (G bright)
(b bright) --cnt (ovr contr) --ccnt (R contr)
(G contr) (B contr) --sat (saturation) --hue (hue)
--cinv (invert) --csp (colorspace) --gamma (gamma)
--mono (monochrome)
