158 ImagePRO-II • User’s Guide
B. Remote Control Protocol
ImagePRO-II Remote Commands
• Query Response 1: Raster Box Settings in the following format:
RASTER --mode (mode)
• Query Format 2 (AOI Output):
RASTER --och (output channel) --aoi --?
• Query Response 2: Raster Box Settings in the following format:
RASTER --mode (mode)
ob`q
• Description: Rectangle Settings
• Required parameters:
--num (index num), for VIEW --pixel commands
--ch (channel), for VIEW --pixel commands
• Parameters:
--num (index num): 0-21
--ch (channel): 0-1
--hpos: -32767 .. 32767
--vpos: -32767 .. 32767
--hsize: 0 .. 32767
--vsize: 0 .. 32767
• Query Format:
RECT --num (index num) --ch (channel) --?
• Query Response: Rectangle settings in the following format:
RECT --hpos (H Position) --vpos (V Position)
--hsize (H Size) --vsize (V Size)
sbo
• Description: Display software and hardware versions
• Command Format:
VER
• Query Format: n/a
scp
• Description: Video Format Settings
• Required parameters:
--con (connector), for input video format
--och (output channel), for output video format
--itype (input type), for commands to DVI input settings
• Parameters:
--con (connector): 0-4
0 = DVI, 1 = HD15, 2 = HDMI, 3 = DP, 4 = SDI1
--och (output channel): 0-1, for output commands
