162 ImagePRO-II • User’s Guide
B. Remote Control Protocol
Legacy Remote Commands
ildlp
• Description: Save current output image in non-volatile memory as Logo image.
• Parameters: None
 LOGOS (Save current output image as Logo image.)
l`opq
• Description: Reset Output Configuration.
• Parameters: None
 OCRST (Reset Output Configuration)
l`p^s
• Description: Save Output Configuration to non-volatile memory.
• Parameters: None
 OCSAV (Save Output Configuration)
lqmj=íóéÉ=ê~ëí=Çá~Ö
• Description: Sets Internal Test pattern mode and raster box mode.
• Parameters:
type: Test Pattern type: type[0..10]
0=Off, 1=H Ramp, 2=V Ramp, 3=100% Col Bars,
4=75% Col bars, 5=16x16 Grid, 6=32x32 Grid, 7=Burst,
8=50% Gray, 9=Gray Steps 1, 10=Gray Steps 2
rast: Raster Box: rast[0-1] On | Off
diag: Diagonal Motion: rast[0-1] On | Off
• Query Format:
OTPM?
Returns the Test pattern mode and raster box mode in the format:
= type rast diag
 OTPM 9 0 (Selects Gray Steps 1 test pattern with raster off)
 OTPM? (Query test pattern mode and with raster box mode)
m^ke=åååKå
• Description: Set Output Horizontal Pan.
• Parameters: nnn.n - Horizontal Pan (-100.0% - +100.0%)
• Query Format:
PANH?
Returns the Output Horizontal Pan value in the format
= nnn.n
 PANH 50 (Set Output Horizontal Pan to 50%)
 PANH? (Queries Output Horizontal Pan)
