4. Menu Orientation
Using the Menu System
rëáåÖ=íÜÉ=jÉåì=póëíÉã
This section describes the conventions for using the ImagePRO-II’s menu system. For
reference, the following illustration shows the Setup Menu.
Figure 4-5. Setup Menu
Please note the following important menu rules and conventions:
• The top line names the current menu, in upper-case letters.
• Subsequent lines typically display two fields:
~ For a function, the left-hand field names the function. The right-hand
field shows the function’s current parameter (or value). In the preceding
illustration, In Auto Acquire is a function and On is its current value.
~ For a submenu, the left-hand field names the submenu that you can
access. The right-hand field displays a double arrow (>>), indicating that
a submenu is available.
In the preceding illustration, Input and Output are two of the available
submenus. To use a submenu, scroll to it and press SEL. Then scroll
through the list that appears.
• The navigation cursor (>) in the left-hand column indicates the current line on
which you can take action. This arrow moves as you rotate the ADJUST knob on
the front panel. When you reach an editable field and press SEL, the navigation
cursor changes to an edit cursor (#)
SETUP
> Input >>
Output >>
In Auto Acquire On
Custom Formats >>
Views >>
Transition >>
System >>
Logo >>
LED Setup >>
Save Snapshot
Tech Support >>
Factory Reset >>
Firmware Upgrade >>
Note
The ImagePRO-II’s display screen is four lines high.
Throughout this chapter, entire menus are shown for ease of
reference, unless otherwise noted.
