ImagePRO-II • User’s Guide 73
4. Menu Orientation
Creating and Saving Views
After you create pan and zoom settings for a view, use the following procedure to
name the view and save it. For information about pan and zoom settings, refer to
Creating a View on page 71.
1. After creating your view with the PAN/ZOOM button, return to the Setup Menu
and select Views. You do not need to save the view in the Zoom/Pan Submenu
first.
The View Submenu appears, as shown in the following illustration.
Figure 4-55. View Submenu
2. Select Save. The Save View Submenu appears.
Figure 4-56. Save View Submenu (sample)
3. Select View to choose a name for your view. You can choose from a list of 16
preset names by turning the ADJUST knob. Then press SEL.
4. Scroll to Save and press SEL again. Your view settings are saved, and a
confirmation message appears.
Figure 4-57. View Saved Message
Note
This procedure saves the view settings, under the name you
select. It does not assign this view to an input. To assign a
system view to an input, refer to the section Recalling a
System View on page 74.
VIEW
> Recall >>
Save >>
Delete >>
SAVE VIEW
> View View1
Save
SAVE VIEW
> View View6
Save
-- View Saved --
