Barco NGS-D320 Lite User Manual

3. Installation
Connector/part Connecting device/use
3
Identification LED Blue On: Upgrading the device firmware (do NOT
cut power from the device)
Blue Blinking: Identification
4
3D input
Stereo (3D)
5
Headset in/out
Headset
6
Audiolineout
Audio device (e.g. PC, LS)
7
Audio line in
Audio device (e.g. PC)
8
Ground Ground
9
USB interface type A (3) USB 2.0 type A, keyboard and/or mouse
10
Micro USB interface Micro USB connector to PC
11
Ethernet interface (RJ45) cage Dual 1Gb Ethernet connection
Left connector: secondary 1Gb ethernet connection
Right connector: primary 1Gb ethernet connection
For both RJ45 connectors: there are two LEDs
inside:
• Left LED (green): activity (Blinking=activity /
OFF=no activity)
• Right LED (green): link status (ON=link present
/ OFF=no link present)
12
Push button
Identification button
3.3 Start up
How t o start up the device
1. After installing the device as mentioned above, apply power to the power source (12V DC).
2. Check if the Power LED is lit green.
3. Check if the applied input and output LEDs are lit green.
20
K5903129 NGS-D320 29/09/2016
