2. Product information
2.3.6 Audio
Audio format
The NGS-D320 supports encoding and decoding 1 stream of Uncompressed RAW audio.i.a.w.
• RFC3551 (RTP Profile for Audio & Video Conferences with Minimal Control)
• RFC2586 (Audio/L16 MIME content type)
Association
The audio stream can be configured to be Associated with a video stream, but Association can also be
disabled, for audio streams which are independent of the video.
2.3.7 USB HID
Remote control
The NGS-D320 supports the use of keyboard and mouse to enable remote control of connected sources
over the network.
HID events are sent across the network i.a.w. VNC (RFB) protocol (RFC6143).
Hardware decoding
When having a setup between an NGS-D320 encoder and NGS-D320 decoder, then:
• Connect any USB keyboard and mouse to the decoder
• Connect the PC via USB to the encoder
• Set the PC keyboard local to match the actual connected keyboard (either use ”locale” or use “layout”).
The network is transparent for keyboard operation. The keyboard acts just as if it was connected to the
PC locally via a USB cable.
By default, the NGS-D320 is configured to have keyboard and mouse operational.
The keyboard and mouse can be disabled, refer to "Encoder settings", page 35.
Software decoding
When having a setup between an NGS-D320 encoder and another Barco software decoder, refer to the
user manual of this specific system.
When having a setup between an NGS-D320 encoder and a 3rd party software decoder, then keyboard
and mouse can function by running a VNC client on the software decoder. However, interoperability and
fluent operation cannot be guaranteed.
K5903129 NGS-D320 29/09/2016
15
