4. Operation
- Associated audio
By default, the audio stream is Associated with the video stream. This also means the RTSP url of
the video stream, will provide both the audio & video stream (via a combined SDP).
This association can also be disabled. This means audio & video streams are sent separately.
- Associated USB
By default, the USB HID stream is Associated with the video stream. This means that this specific
video port can be remote controlled.
This also means the RTSP url of the video stream, will provide both the USB HID & video stream
(viaacombinedSDP).
This association can also be disabled. This means USB & video streams are sent separately.
Note: Combined SDPs do not work correctly with VLC. Video will not pla y back.
Disable the associated audio & USB to allow software decode & video playback with VLC.
6. Press Apply to save settings.
4.5.3.4 HDMI Audio In
1. The Encoding profile is by default set to “auto”. Select the desired Encoding profile.
To disable Encoding explicitly for an input: Select (disabled) in the encoding profile drop down list.
Image 4-19
Encoder settings HDMI Audio In
2. Define the destination/port in the Destination field.
- Multicast: valid multicast address/port
- Unicast: leave the destination field empty
4.5.3.5 USB Host
Emulated keyboard layout
1. An emulated keyboard layout of the host can be associated with one video input. By default, this is set
to native, and associated will be made with the first connected input.
Image 4-20
Encoder settings US B Host
2. Press Apply to save settings.
K5903129 NGS-D320 29/09/2016
37
