6. Input & communication
6.6 Integrated Media B lock/Server (optional)
Depending on the projector configuration the projector card cage is either equipped with an ICP or ICMP. In
case an ICP is installed then an IMB, IMS , or HDSDI input module can be optionally inserted into the slot below
the ICP. This is n ot the case if the ICMP is installed. For m ore informa tion abo ut the ICMP see chapter called
ICMP.
Integrated Media Bloc k (IMB)
Image 6-7
Example of IMB powered by Doremi.
Integrated Media Server (IMS)
Image 6-8
Example of IMS powered by Doremi.
Configuration and operation instructions for IMB and IMS are not included in this document. See manufactur-
ers website of the installed IMB/IMS for technical documen tation and support.
R5905963 PROMETHEUS SERIES 09/03/2015 101
