6. Input & communication
6.5 Quad 3G-SDI Input Module (optional)
Location and source input ports
SEL
SYNC OK
SEL
SYNC OK
SEL
SYNC OK
SEL
SYNC OK
QUAD 3G/SDI INPUT
ABCD
Image 6-5
The f ollowing input c ombinations are possible : A, B, A+B, A +B+ C+D
When using all 4 four inputs to create the image connect the quadrants of the image to the inputs as indicated on the drawing.
A B
DC
Image 6-6
Quadrant connection
To c on figure the input, consult the Communicator manual
