Barco Prometheus I - Realignment of the Lamp in Its Reflector (Manual Lamp House)

4. Lamp & Lamp House
4.12 Realignment of the lamp in its reflector (manual Lamp House)
Each xenon lamp installat ion requires a realign ment of the lamp in its reflector for optimal performance of the
xenon lamp in the Pro metheu s. F urthermore, it is recomme nded t o realign the lamp afte r the first run time of
100 and 200 hours. Especially the Z-axis of the lam p.
How to realign
1. Remove the lam p cover to get ac cess to the X-, Y - and Z-axis adjustment thumbscrews of the lam p.
2. Some lamp houses may have lock nuts on the X and Y adjustment screws w hich are locked. Before starting the adjustmen t, fully
turn these lock nuts against the thumbscrew.
Image 4-51
Lock nuts
3. Switch on the projector and start up the lam p.
4. Go via the Communicator touch panel to the menu “Insta lla tion” > “Lam p ” > “Light output”.
5. Set the “Light output mode”innormal mode and the “Lamp Dimming” on max imum (255).
Note: This window on the Communicator touch pan el shows in the upper left corner the m easured value of the built-in light
sensor of the projector.
Image 4-52
Light mode selection
R5905963 PROMETHEUS SERIES 09/03/2015 67
