5. Lenses & lens holder
If yes, the Back Focal Length is correctly adjusted.
If no, repeat with step 4.
9. Is the projected image in the c orners as sharp as in the middle?
If yes, proceed with the procedure "Fixation of the Lens Holder front plate", page 86.
If no, Scheimpflug adjustment is required. See procedure "Scheimpflug adjustment", page 82, prior to fixate the Lens Holder
front plate. CAUTIO N: Skip the action, in the Sc heimpflug adjustment procedure, to turn the three Scheimp flug ad justment nuts
until the front of the nut is equally aligned with the front of the threaded rod!
R5905963 PROMETHEUS SERIES 09/03/2015
81
