Barco UDM User Manual

55R5911443 /11 UDM
GUI – Pulse software menu tree
Test pattern x
Warped test
pattern
Custom test
pattern y
O
Add command
Edit command
Clear all (action)
Status screen
About
Remote access
Camera preview
(on/o)
Source preview
(on/o)
Advanced settings
Native RealColor
Laser banks
Tilt sensor
calibration
Statistics
Maintenance
Factory reset
Frame calibration
Flex brightness
Flex resolution 
Electronic
convergence
Login to
advanced settings
Lens calibration
General
Open source
license list
SystemPower
Cooling mode
Capture mode
(on/o)
Operational mode
User interface
Language
Units
Backlight
Themes
Communication
Remote control
LAN
HBaseT
WiFi
DMX
GSM
Cloud services
Regulatory
information
Host name
Product
registration
Auto dim
Auto light
source o
Auto standby
Date and time
Lens features
Prole Edit
New Prole
Delete prole x
(action)
Assign prole x
to preset (action)
Prole x (activate)
Warp
Warp (on/o)
Screen size
Warp les
Transport delay
4 corners
Bow
Blend and mask
Basic blend
Blend mask
Black level les
Black level
Blend les
Lens
Position
Zoom & focus
Shift
Tilt sensor
Dynamic focus
(on/o)
Shift to center
(action)
Shutter mode
Laser ranging
Motorized frame
Scaling
Illumination
3D
Center motorized
frame (action)
Orientation
Contrast
Brightness
Saturation
Sharpness
Gamma
Digital zoom
and shift
Tilted brightness
uniformity
Advanced Settings
Realcolor P7
Output resolution
HDR
Dynamic black
No source image
Lx Quad combo
Quad SDI
Connector settings
Connector x
Lx Quad DP
Stitched options
Connector settings
Connector x
Lx SFP Input
Connector settings
Connector x
Image Proles
Settings Test patterns Scheduler
Status
Source
Installation
Image 5–5 Menu tree of the Pulse software, with the following footnotes
1 Only visible if specific option is installed
2 Only visible on 4K models with actuators
3 Only visible when motorized lens is installed
4 Only visible when logged in as service user
5.2 Navigation
Navigation via the RCU or local keypad
Navigating the OSD can be done using the remote control or the local keypad.
GUI – Introduction

Barco UDM Specifications

General

Brand	Barco
Model	UDM
Category	Projector
Language	English
