Bard LC6000-200 User Manual

TABLE 7
LC6000-200 to Sensor Connection Index
LC6000
Sensor Terminal Description
TB# Wire Mark
12 B2 8403-079 (Indoor Temp/Hum) OUT H Zone 1 Indoor Remote Humidity Sensor
13 GND 8403-079 (Indoor Temp/Hum) M (GO) Ground
14 B3 8403-079 (Indoor Temp/Hum) OUT H Zone 2 Indoor Remote Humidity Sensor
15 GND 8403-079 (Indoor Temp/Hum) M (GO) Ground
16 B4 8403-079 (Indoor Temp/Hum) OUT H Zone 3 Indoor Remote Humidity Sensor
17 GND 8403-079 (Indoor Temp/Hum) M (GO) Ground
18 B6 8403-079 (Indoor Temp/Hum) NTC OUT Zone 1 Indoor Temperature Sensor
19 GND 8403-079 (Indoor Temp/Hum) NTC OUT Ground
20 B7 8301-058 (Indoor Temp Only) NTC OUT Zone 1 Indoor Remote Temperature Sensor
21 GND 8301-058 (Indoor Temp Only) NTC OUT Ground
22 VDC+ 8403-079 (Indoor Temp/Hum) + (G) Power for B2 (Z1 Humidity)
23 VDC+ 8403-079 (Indoor Temp/Hum) + (G) Power for B3 (Z2 Humidity)
24 VDC+ 8403-079 (Indoor Temp/Hum) + (G) Power for B4 (Z3 Humidity)
26 B8 8403-079 (Indoor Temp/Hum) NTC OUT Zone 2 Indoor Remote Temperature Sensor
27 GND 8403-079 (Indoor Temp/Hum) NTC OUT Ground
28 B9 8403-079 (Indoor Temp/Hum) NTC OUT Zone 3 Indoor Remote Temperature Sensor
29 GND 8403-079 (Indoor Temp/Hum) NTC OUT Ground
65 24 VAC+ 8301-090 (Outdoor Temp/Hum) 2 24 VAC Supply for Outdoor Humidity Sensor
66 24 VAC- 8301-090 (Outdoor Temp/Hum) 3 24 VAC Ground for Outdoor Humidity Sensor
67 B11 8301-090 (Outdoor Temp/Hum) 1 Signal for Outdoor Humidity Sensor
69 D14 Bard Guard 14 Bard Guard Alarm Signal
70 B12 8301-090 (Outdoor Temp/Hum) 4 Signal for Outdoor Temperature Sensor
71 GND 8301-090 (Outdoor Temp/Hum) 5 Ground for Outdoor Temperature Sensor
72 GND Bard Guard 15 Ground for Bard Guard Alarm Signal
Manual 2100-669F
Page 35 of 37
