Baroness LM331 - Mower Units

Speed
(HST)
Forward
2WD 14.0 km/h 8.70 mph
3WD 8.7 km/h 5.41 mph
Reverse
2WD 10.0 km/h 6.22 mph
3WD 6.2 km/h 3.85 mph
Speed (Mechanical) -
Efficiency
11,712 m
2
/h (8.0 km/h x
mowing width x 0.8)
2.89 acres/hour (4.97 mph
x mowing width x 0.8)
Maximum inclination for operation 15 degrees
Tire size
Front wheel 20 x 12.00-10 4P
Rear wheel 20 x 8.00-10 4P
Tire pneumatic pressure
Front wheel
140 kPa (1.4 kgf/cm
2
)
20 psi
Rear wheel
140 kPa (1.4 kgf/cm
2
)
20 psi
Battery 75D23L
Engine plug -
The factory default maximum engine rpm is 2,800 rpm.
Mower Units
Baroness mower unit that can fit this machine is the model marked with a circle in the "Attachable
unit" column.
LM331
Baroness mower unit Model Attachable unit Remarks
Small diameter mower unit LH52 22 in -
Multi configuration mower unit
LH62 22 in -
LH66 26 in 〇
Standard mower unit
LS62 22 in -
LS66 26 in 〇
Product Overview
LM331
Product Overview
Page 3-3
Specifications
