Baroness LM331 - About Lubrication; Lubricating Points; Lubrication

Lubrication
About Lubrication
It is necessary to lubricate moving parts so that
they will not become stuck or damaged.
The locations where lubricant is used are
indicated in "Lubricating Points".
Apply the lubricant.
Lubricating Points
Apply lubricant at the following locations every
50 hours of operation.
2
3
1
8bq62b-485
Lubricating Points_001
Location
No. of
greasing
points
1
Steering cylinder spherical
bearing
2
2
Front mower cylinder spherical
bearing
2
3
Rear mower cylinder spherical
bearing
1
Steering cylinder spherical bearing
There are two locations.
8bq62b-487
Lubricating Points_002
1.
Front mower cylinder spherical bearing
There are two locations.
8bq62b-488
Lubricating Points_003
8bq62b-489
Lubricating Points_004
Rear mower cylinder spherical bearing
There is one location.
8bq62b-490
Lubricating Points_005
2.
3.
Maintenance
LM331
Maintenance
Page 6-7
Lubrication
