Baroness LM331 - Description of Operation Decals

Description of Operation Decals
Key Switch Mark
Key switch mark
This indicates the key switch positions.
STOP
1
4
3
2
rcyo1p-002
Key Switch Mark_001
1
OFF
2 ON
3 GLOW
4 START
Engine Rotation Decal
Engine rotation decal
This indicates high/low speed of the engine
rotation.
1
2
kp2t9l-002
Engine Rotation Decal_001
1
High speed
2 Low speed
Light Switch Decal
Note:
Depending on the specifications, this function
may not be available.
LM331--1105Z0
Light switch decal
This indicates the light switch positions.
1
2
mzmbmi-002
Light Switch Decal_001
1
ON
2 OFF
Mower Unit Up/Down Decal
Decal, mower unit up/down
This indicates the Up/Down positions of the
mower unit.
1
2
8kzlbt-001
Mower Unit Up/Down Decal_001
1
Down
2 Up
LM331
Product Overview
Page 3-16
Operation Decals
