Remove the ring nut, and then remove the
cup.
3
2
1
v1spa6-006
Draining of Water Separator_002
1
Ring nut
2 Cup
3 Element
Drain the water from the cup.
Important
During installation, prevent contamination with
dirt or dust.
If the fuel is contaminated with dirt or dust
etc., the fuel injection pump and injection
nozzle will become worn.
Correctly install all parts in their original
positions.
Fill up the fuel tank with fuel, and then open
the fuel cock of the fuel filter.
Open the fuel cock of the water separator.
1
2
A
B
v1spa6-005
Draining of Water Separator_003
1
Fuel cock
2 Air-bleeding plug
A ON (open)
B OFF (close)
Loosen the air-bleed plug to bleed the air.
When the cup is filled with fuel, close the
air-bleed plug.
5.
6.
7.
8.
9.
10.
11.
If the engine does not start within 15
seconds after switching the ignition key to
the "START" position, wait at least 30
seconds, and then repeat the same
operation.
If there is still air in the cup after starting the
engine, bleed the air again.
Cleaning of Water Separator
Important
Water-contaminated fuel may impair engine
startability, decrease output or damage engine
parts.
Clean the water separator according to the
maintenance schedule.
And clean it whenever debris has
accumulated in the cup.
Stop the engine, and then turn the key
switch to the "OFF" position.
Place a container under the water
separator.
Close the fuel cock of the fuel filter.
Close the fuel cock of the water separator.
1
2
A
B
v1spa6-005
Cleaning of Water Separator_001
1
Fuel cock
2 Air-bleeding plug
A ON (open)
B OFF (close)
12.
1.
2.
3.
4.
