Scanning the tunable receiver
Setting up scan frequencies
The Barrett 950 can scan any range of frequencies from 500 KHz to 30 MHz with a
frequency step down to 1 Hz.
To set up the frequency scan parameters on the Barrett 950, enter the tuning receiver mode,
then:-
... hold down until the following is displayed:-
Enter a new frequency, using the numeric keys, to set the first scan limit boundary - example
below shows Scan Limit 1 set to 12 MHz:-
... until display below appears
Note:- The frequency of 12000.000 may not appear as shown above, this indicates the
last scan limit boundary programmed was 12000 kHz which will not always be the
case
BARRETT 950 HF TRANSCEIVER
PAGE 46
