Barrett 950 - Programming Cable Schematic

BARRETT 900 SERIES TRANSCEIVERSBARRETT 900 SERIES TRANSCEIVERS
900 Programming Cable Schematic
PAGE 135
BCA90023 900 PROGRAMMING CABLE
LENGTH 1.5 METRE
B
DB9F SOLDER TYPE
P/No: 4017A
A
B
7
2
3
BLUE
RED
YELLOW
GND
RxD/TxD
TxD/RxD
COLOUR
SIGNAL
CABLE CORE DETAILS
5
3
2
DB25
3
2
7
P/No: 9651
ADAPTER DB25F
To DB9M
9 CORE CABLE
P/No: 6582
P/No: 4017
DB9 SHELL
P/No: 4023A
DB25 SHELL
P/No: 4023
DB25M SOLDER TYPE
A
930, 950, 980 Programming
Cable Schematic
