BARRETT 900 SERIES TRANSCEIVERS
11.0 Auxiliary connector
11.1 Barrett 980 and Barrett 950 transceivers
Pin Name Description of function Level Option required
to activate
- Note 2
- Note 2
- Note 2
- Note 2
1 Ground Ground 0V None
2 Rx Data RS-232 data input True RS-232 BCO95003
3 Tx Data RS-232 data output True RS-232 BCO95003
4 External Power On For use with Barrett 960 or ancilliary equipment. Low to activate None
5 External Speaker External speaker output 0-10V None
6 Tuned In Antenna tune cycle complete input from 910 / 911 Low going pulse None
7 RS-232 Gnd. RS-232 Ground 0V None
8 ALC / Ext. GPS In Ext. ALC from Linear Amp / Ext. GPS Input (with pin 20) 0-10V / NMEA 0183 BCO95002/3
9 Auxiliary PTT In Auxiliary PTT input Low to activate PTT None
10 Scan Stop Scan stop input from external modem Low to stop scan None
11 Bal. Tx Audio In Balanced external Tx audio input (with pin 24) 600 Ohms 0dBm. None
12 Bal. Rx Audio Out Balanced un-muted Rx audio output (with pin 25) 600 Ohms 0dBm. None
13 Ground Ground 0V None
14 Ant 0 / Pre-amp on Channel no. output Octal bit 0 / 910 pre-amp on Active low None
15 Ant 1 Channel no. output Octal bit 1 Active low None
16 Ant 2 Channel no. output Octal bit 2 Active low None
17 External Alarm Out / Horn / Latched alarm out (selcall activated) Active low BCO95002/3
18 13.8 V Int Out Interrupted 13.8 V for 910 Auto. Antenna 13.8V-0V None
19 Ant 0 / Pre-amp on 910 pre-amp on / Channel no. output Octal bit 0 Active low None
20 FSK / Ext. GPS in FSK digital input / Ext. GPS Input (with pin 8) Active low / NMEA BCO95002/3
21 PTT / C-Mute Out PTT Out / Receiver Cross Mute Out Active low None
22 CW Key Input from CW Key Low to activate None
23 +13.8 V Fused Out +13.8V Output to power auxilliary equipment 13.8V @ 2 Amp. None
24 Bal. Tx Audio In Balanced external Tx audio input (with pin 11) 600 Ohms 0dBm. None
25 Bal. Rx Audio Out Balanced un-muted Rx audio output (with pin 12) 600 Ohms 0dBm. None
Note 1:- Pin 8 and Pin 20 - External GPS input is selected using a menu function or set during programming when the software option required is fitted.
Note 2:- These outputs provide channel information for use with antenna select units such as the BARRETT 916. The outputs are octal coded 0 to FF
representing the least significant digit of the channel number selected. i.e. octal 0 for channel 1, octal 1 for channels 2, octal 3 for channels 2, to
octal FF for channel 16/
/
Ant 3 Channel no. output Octal bit 3
0183
- Note 2
PAGE 54
