BARRETT 900 SERIES TRANSCEIVERS
Voltage table
Location Drawing No. Supply Test Voltage Voltage Source PCB
rail point Receive Transmit and
name regulator or
transistor
nominal nominal source
PA 900S18##.PCB +10 - +10V +/- +10V +/- PA - U5
0.2V 0.2V
PA 900S18##.PCB +5 - +5V +/- +5V +/- PA - U2
0.2V 0.2V
RF/Audio 900S15##.PCB +14 - +13.8 V +13.8 V PA - external
900S27##.PCB nominal nominal source
RF/Audio 900S15##.PCB +10 - +10V +/- +10V +/- PA - U5
900S27##.PCB 0.2V 0.2V
RF/Audio 900S15##.PCB +5 - +5V +/- +5V +/- PA - U2
900S27##.PCB 0.2V 0.2V
RF/Audio 900S15##.PCB BIAS TP12 +5V +/- +5V +/- RF/Audio - U5:B
900S27##.PCB 0.2V 0.2V
Micro. 900S14##.PCB +14 - +13.8 V +13.8 V PA -external
nominal nominal source
Micro. 900S14##.PCB +10 - +10V +/- +10V +/- PA - U5
0.2V 0.2V
Micro. 900S14##.PCB +5 TP14 +5V +/- +5V +/- PA - U2
0.2V 0.2V
Micro. 900S14##.PCB +5D TP4 +5V +/- +5V +/- Micro - U19*
0.2V 0.2V
Micro. 900S14##.PCB +5VA TP3 +5V +/- +5V +/- Micro -U20*
0.2V 0.2V
Fr. Panel 900S16##.PCB +14 - +13.8 V +13.8 V PA - via RF/Audio
nominal nominal
Fr. Panel 900S16##.PCB +5 - +5V +/- +5V +/- Fr. Panel - Q6
0.2V 0.2V
Rem. Head 900S17##.PCB +14 - +13.8 V +13.8 V PA - via
nominal nominal RF/Audio
Rem. Head 900S17##.PCB +10 - +10V +/- +10V +/- Rem. Head - U7
0.2V 0.2V
Rem. Head 900S17##.PCB +5 - +5V +/- +5V +/- Rem. Head -U6
0.2V 0.2V
PA 900S18##.PCB 14 TP7 +13.8 V +13.8 V external
PA 900S18##.PCB +5TX - 0V +5V +/- 0.2V PA Q16
PA 900S18##.PCB +10TX - 0V +10V +/- 0.2V PA - Q8
PA 900S18##.PCB +12TX - 0V +12V nominal PA - Q9
Note :- ## denotes the rev number, this may change
