4 Product description
Handscanners
BCS 3600
ex
series
24 / 72
Subject to technical modifications
17/05/18
Connection of hand-held scanners to HMI (only Zone 2 and 22)
The BCS 3608
ex
-NI hand-held scanner can be connected to the HMI using the following cables:
Cable specified for connection to HMI Version Length BARTEC Order No.
Limiting cable RS 232 1.9 m B7-A2Z0-0040
Limiting cable USB 1.9 m B7-A2Z0-0041
Tab. 11: Connection cable for hand-held scanner to the host PC
The cables set out in Tab. 11 have been approved for use in potentially explosive atmospheres in
Zones 2, 22 and Class I Division 2.
Data cable from the universal supply module to the host PC
We recommend using a standard, shielded data cable (CAT 7) as data line to prevent external
disturbances to data transfer.
Interface Recommended cross-section Number of cores
RS232/RS482/RS485
0.2 mm
2
to 2.5 mm
2
5
USB 4
Tab. 12: Data line from the universal supply module to the host PC
