7 Connection /
commissioning (qualified
personnel)
Subject to technical modifications
17/05/18
51 / 72
3. Feed the connection cable through the cable gland.
4. Connect the cradle to the power source.
7.4 Connecting to the HMI: connecting the hand-held scanner to the HMI
The function is only guaranteed if the cables you connect for your configuration have been
specified by BARTEC (see system overview, Chapter 15.2, P. 70).
Pay attention to the HMI manual.

Connect the connection cable of the hand-held scanner in the HMI to the designated terminals.
