7.2.2 Connecting the universal supply module to an HID device
All interfaces used on the universal supply module (USB, RS232, RS422 and RS485) can be
connected to an HID device.
The prerequisite is a software wedge application on the PC / host using which the interface data can
be converted into USB-HID. Software wedge applications are not supplied by BARTEC, but they are
available on the market (e.g. T-Wedge).
7.2.3 Connecting the universal supply module to a PLC
All interfaces used on the universal supply module (USB, RS232, RS422 and RS485) can be
connected to a PLC.
The available interfaces depend on your PLC.
Solution 1: availability on the PLC side
Fig. 14: Availability on the PLC side
‒ Communication controller / processor (CP)
‒ Open ASCII driver
