Jog Keys
Four arrow keys position the hoop by moving the pantograph under the needle. The
arrows point in the opposite direction that the pantograph moves. Vertical movements
are from left to right and horizontal movements are from front to back.
The jog keys move the pantograph in single pulse movement of 0.1mm, by pressing the
key once; continuous movement, by pressing and holding the key down; and
microfeed movement, by pressing the key once briefly and quickly pressing it a second
time, then holding it down.
Origin Key
The unmarked key in the center of the jog keys, moves the pantograph back to the
starting point, or the origin, of the pattern.
On/Off Keys
Turn the power to the machine on or off directly from the automat. The machine beeps
one long beep indicating it has been powered on.
NOTE: The On/Off keys on the automat do not turn off the driver box
power.
Built-In Floppy Disk Drive
The BENS has a built-in 3.5" floppy disk drive by which patterns can be read into
internal memory for permanent storage.
BENS Operation Guide - 12/99 Overview 1-13
