SIZE Overall dimensions of the pattern, from lower left to upper right
corners, measured in tenths of millimeters.
P1 Distance between the start point and bottom left corner of the pattern,
measured in tenths of millimeters.
P2 Distance between the start point and top right corner of the pattern,
measured in tenths of millimeters
Free st Total number of stitches available in memory.
The Pattern Characteristics screen also has options pertaining to patterns stored in
memory: Function List, Rename, and Product List.
Viewing Pattern Characteristics
1.
Press the Memory softkey. The Pattern List displays, showing the
patterns stored in memory.
2.
Use the jog keys to select a pattern from the list. A box outline
displays around the selected pattern.
3.
Press B, below the Pattern Characteristics icon, to open the Pattern
Characteristics screen.
4.
Press B again to close the Pattern Characteristics screen, and return to
the Pattern List screen. Press the Memory softkey to close the Pattern
List screen.
Function List
The Function List option, available at the Pattern Characteristics screen,
displays a list of all color change function codes in the selected pattern.
BENS Operation Guide - 12/99 Memory Operations 2-11
Memory
Softkey
