Barudan BENS - Cables and Connectors

BENS CONNECTIONS
FROM PORT TO PORT CABLE
BENS COM BP-II Input: 2 (Serial) COM
BENS COM UTP-III COM COM
BENS COM FDR-III COM COM
BENS COM FDR-V COM COM
FMC Data Out BENS Tape E & B
FMC-II Data Out 1 BENS Tape E
FMC-II Data Out 2 BENS Tape B & E
LD-II Data Out 1 BENS Tape B & E
LD-II Data Out 2 BENS Tape B & E
PTR-5 Data Out BENS Tape E
FDR-III Tape Out BENS Tape E
FDR-V Tape Out BENS Tape E
FDR-III COM BENS COM COM
FDR-V COM BENS COM COM
JM-II Data Out BENS Tape B & E
JM-IV Data Out BENS Tape B & E
Cables and Connectors
There are two reader cables used to connect the BENS to Barudan peripheral
devices. The illustrations on the following page will help you identify the
connectors.
