Product Overview
ITEM INDICATOR REMARK FUNCTION & DESCRIPTION
1
2
Power
USB
PWR
Front Panel
If the “Green” indicator is on, NVR is getting power normally.
USB port
Rear Panel (For reference only)
Connect power supply
Switch power on/off
Connect external sensor or alarm device
Audio signal output, RCA interface
Connect monitor with VGA port
Connect monitor with HDMI port
Connect USB devices, such as USB mouse
Connect to internet / router / network
Connect camera(s) – support PoE
ITEM PORT CONNECTION METHOD
Power Port
Power Switch
Sensor/Alarm
Audio Output
VGA Port
HDMI Port
USB Port
INTERNET Port
LAN Port
1
2
3
4
5
6
7
8
9
1 3
2
4 5 6 7 8 9
