BE1-11m Starts per Time Interval (66) Test
Step 7: Apply 10 Aac three-phase current for approximately one minute (simulate motor starting). Note
that this is the second start. Verify that OUT1 (Starting) and OUT3 (Start Blocked) close and
OUT 2 (Stopped) opens.
Step 8: Remove three-phase current. Verify that OUT1 (Starting) opens and OUT2 (Stopped) closes.
Verify that OUT3 (Start Blocked) remains closed.
Step 9: Wait approximately three minutes for timing to complete. Stop the timer when OUT4 (Start
Block Removed) closes and record the time. The expected timing is 360 seconds (6 minutes).
Note that OUT3 (Start Blocked) opens when OUT4 (Start Blocked Removed) closes.
Functional Test Report
Timing Verification
Time Interval Range = 1 to 1,440 min
Timing Accuracy = ±0.5%
