Basler BE1-11m User Manual

80-10 9424200996
Specifications BE1-11m
Option 2 (125/250 Vac/dc)
DC Operating Range ................................................. 90 to 300 Vdc
AC Operating Range ................................................. 90 to 270 Vac
Option 3 (24 Vdc)
Operating Range ....................................................... 17 to 32 Vdc (down to 8 Vdc momentarily)
Frequency Range
Options 1 and 2 only ................................................. 40 to 70 Hz
Burden
Options 1, 2, and 3 .................................................... 12 W continuous, 14 W maximum with all outputs
energized
Output Contacts
Make and Carry for Tripping Duty ............................. 30 A, 250 Vdc for 0.2 seconds per IEEE Std C37.90-
2005 - IEEE Standard for Relays and Relay
Systems Associated with Electric Power
Apparatus; 7 A continuous AC or DC
Break Resistive or Inductive...................................... 0.3 A at 125 or 250 Vdc (L/R = 0.04 maximum)
Terminals
OUT 1 ........................................................................ C1, C2
OUT 2 ........................................................................ C3, C4
OUT 3 ........................................................................ C5, C6
OUT 4 ........................................................................ C7, C8
OUT 5 ........................................................................ C9, C10
OUT 6 ........................................................................ E11, E12
OUT 7 ........................................................................ E9, E10
OUT 8 ........................................................................ E7, E8
OUT A ....................................................................... C11, C12
Contact-Sensing Inputs
Maximum Input Voltage
The maximum input voltages are the highest voltage for each power-supply range listed under the Power
Supply section.
Turn-On Voltage
Contact-sensing turn-on voltages are listed in Table 80-1.
Table 80-1. Contact-Sensing Turn-On Voltages
Style Option Nominal Input Voltage
Contact-Sensing Turn-On Voltage*
Jumper Installed
(Low Position) †
Jumper Not Installed
(High Position) †
Mxx1xxxxxxxxxx 48 Vdc or 125 Vac/dc 26 to 38 Vdc
69 to 100 Vdc
56 to 97 Vac
Mxx2xxxxxxxxxx 125/250 Vac/dc
69 to 100 Vdc
56 to 97 Vac
138 to 200 Vdc
112 to 194 Vac
Mxx3xxxxxxxxxx
24 Vdc
n/a
Approx. 5 Vdc
* AC voltage ranges are calculated using the default recognition time (4 ms) and debounce time (4 ms).
† Voltage ranges depend on jumper configurations. See the Contact Inputs and Outputs chapter for more
information.
