Specifications BE1-11m
Clock Holdup
Capacitor Holdup Time ............................................. Up to 24 hours depending on conditions
Battery Holdup Time ................................................. Greater than 5 years depending on conditions
Battery Type .............................................................. BR2032 or CR2032, coin-type, 3 Vdc, 195 mAh
Basler Electric P/N 38526
Caution
Replacement of the backup battery for the real-time clock should be
performed only by qualified personnel.
Observe polarity markings on the battery socket while inserting a new
battery. The battery polarity must be correct in order to provide backup
for the real-time clock.
Note
Failure to replace the battery with Basler Electric P/N 38526 may void
the warranty.
Communication Ports
Communication ports consist of USB, serial, and Ethernet connections.
USB
A front-panel B-type USB connector provides local communication with a PC operating BESTCOMSPlus®
software. Compatible with USB 2.0 specification.
Data Transfer Speed ................................................. 12 MB/s (Full Speed)
RS-485
Rear-panel RS-485 port (compression terminals) that supports Modbus and DNP3.
Port Speed (Baud) .................................................... Up to 115,200
Terminals
A ................................................................................ A3
B ................................................................................ A4
C ................................................................................ A5
Ethernet (Optional)
Either an RJ45 or a fiber optic Ethernet port is available. See style chart. These connectors provide
dynamic addressing (DHCP), web pages (HTTP), e-mail alerts (SMTP), network time protocol (NTP) to
synchronize the real-time clock, as well as communication with BESTCOMSPlus software. Modbus,
DNP3, and IEC 61850 communication through Ethernet is optional.
Copper Type (RJ45 Connector)
Version ...................................................................... 10BASE-T/100BASE-TX
Maximum Length (One Network Segment) ............... 328 ft (100 m)
Fiber Optic Type (ST Connector)
Version ...................................................................... 100BASE-FX, multimode
Maximum Length (Half-Duplex) ................................ 1,310 ft (399 m)
Maximum Length (Full-Duplex) ................................. 6,600 ft (2,011 m)
