BE1-11m Specifications
Input Burden
Burden values shown in Table 80-2 assume nominal value of input voltage applied.
Table 80-2. Contact-Sensing Input Burden
Style Option Nominal Input Voltage
Jumper Installed
(Low Position)
Jumper Not Installed
(High Position)
Recognition Time
Programmable ........................................................... 4 to 255 ms
All timing specifications are for the worst-case response. This includes
output contact operate times and standard BESTlogicPlus operation
timing but excludes input debounce timing and nonstandard logic
configurations. If a nonstandard logic scheme involves feedback, then
one or more BESTlogicPlus update rate delays must be included to
calculate the worst-case delay. An example of feedback is logic
outputs driving logic inputs. For more information, see BESTlogicPlus.
Terminals
IN1 ............................................................................. B1, B2
IN2 ............................................................................. B3, B4
IN3 ............................................................................. B5, B6
IN4 ............................................................................. B7, B8
IN5 ............................................................................. E1, E2
IN6 ............................................................................. E3, E4
IN7 ............................................................................. E5, E6
IN8 (Optional) ............................................................ E7, E8
IN9 (Optional) ............................................................ E9, E10
IN10 (Optional) .......................................................... E11, E12
IRIG Interface
Standard ........................................... 200-98, Format B002, and 200-04, Format B006
Input Signal ...................................... Demodulated (dc level-shifted signal)
Logic High Level ............................... 3.5 Vdc, minimum
Logic Low Level ............................... 0.5 Vdc, maximum
Input Voltage Range ........................ –10 to +10 Vdc
Input Resistance .............................. Nonlinear, approximately 4 kΩ at 3.5 Vdc,
3 kΩ at 20 Vdc
Response Time ................................ <1 cycle
Terminals.......................................... A1, A2
Real-Time Clock
Clock has leap year and selectable daylight saving time correction. Backup capacitor and standard
backup battery sustain timekeeping during losses of BE1-11m operating power.
Resolution ................................................................. 1 s
Accuracy.................................................................... ±1.73 s/d at 77°F (25°C)
