BE1-11m Sequence of Events
32 • Sequence of Events
A sequence of events recorder (SER) report is very useful in reconstructing the exact sequence and
timing of events during a power disturbance or even normal system operations. The SER tracks over 700
data points by monitoring the internal and external status of the BE1-11m. Data points are scanned every
quarter-cycle. All changes of state that occur during each scan are time tagged to 1 millisecond
resolution. Over 1,000 records are stored in nonvolatile memory; when the SER memory becomes full,
the oldest record is replaced by the latest one acquired.
The SER monitors the following points and conditions:
• Single-state events such as resetting demands or targets, changing settings, etc.
• Programmable logic variables
• Targets
• Relay trouble alarm variables
• Programmable alarm variables
• Output contact status
• Fault reporting trigger expressions
BE1-11m protection systems have three BE1-11m identification fields: Device ID, Station ID, and User ID.
These fields are used in the header information lines of the sequence of events records. Refer to the
BESTCOMSPlus® Software chapter for information on BE1-11m identification settings.
For user-programmable logic variables (contact sensing inputs, contact outputs, and virtual control
switches), the user-programmed variable name, and state names are logged in the SER report instead of
the generic variable name and state names.
When a monitored event occurs or a monitored variable changes state, the SER logs all event data listed
in Table 32-1.
Table 32-1. Event Data Recorded
Event Data
Recorded
Description
TIME STAMP
Date of change in format YYYY-MM-DD
Time of change in 24 hour format HH:MM:SS.mmm
SYNC
Time Sync Status, one of: IRIGB, DNP, NTP, RTC, NO_SYNC
DEVICE ID
User entered device name string
TYPE
Point Type, one of: ALRM (alarm), CONF (configurable), LGIC (logic), PROT
(protection), STAT (status), TRBL (trouble), TRGT (target), USER (user)
NUM
Basler Point Name (not localized to local language)
DESCRIPTION
Localized or user entered string description of point
STATUS
Localized or user entered string status of point (Open, Closed, Trip, etc.)
Sequence of Events Setup
The Sequence of Events Setup screen is shown in Figure 32-1. Select events to be recorded in the
Sequence of Events Log. All events are enabled by default.
