BE1-11m Restart Inhibit Test
Step 15: Remove three-phase current. Verify that OUT1 (Starting) opens and OUT2 (Stopped) closes.
Step 16: Apply 10 Aac three-phase current. Verify that no start is possible and OUT2 (Stopped) and
OUT3 (Start Blocked) remain closed during the time between starts.
Step 17: Stop the timer when OUT4 (Start Blocked Removed) closes and record the time. The expected
timing is 60 seconds. Note that OUT3 (Start Blocked) opens when OUT4 (Start Blocked
Removed) closes.
Step 18: Apply 10 Aac three-phase current (simulate motor starting) and verify that a start is possible.
Remove three-phase current.
Functional Test Report
Restart Delay
Restart Delay Range = 0 to 7,200 min
Timing Accuracy = ±0.5% or ±3 cycles, whichever is greater
Step
Time Interval
Low
Actual Timing
High
Pass/Fail
8
60 s (1 min)
59.7 s
60.3 s
P / F
Time Between Starts
Time Between Starts Range = 0 to 7,200 min
Timing Accuracy = ±0.5% or ±3 cycles, whichever is greater
Step
Time Interval
Low
Actual Timing
High
Pass/Fail
17
60 s (1 min)
59.7 s
60.3 s
P / F
