Basler BE1-11m User Manual

9424200996 82-3
BE1-11m Time Curve Characteristics
Table 82-2. Characteristic Curve Cross-Reference
Curve
Curve Name
Similar To
S1
CO Short Inverse
ABB CO-2
S2
IAC Short Inverse
GE IAC-55
A
Standard Inverse
Refer to BS 142
A1
IEC Inverse
Refer to IEC 60255-151 Ed. 1
I1
CO Inverse Time
ABB CO-8
I2
IAC Inverse Time
GE IAC-51
M
CO Moderately Inverse
ABB CO-7
D1
IEEE Moderately Inverse
Refer to IEC 60255-151 Ed. 1
L1
CO Long Inverse
ABB CO-5
L2
IAC Long Inverse
GE IAC-66
G
Long Time Inverse (I
2
t)
Refer to BS 142
V1
CO Very Inverse
ABB CO-9
V2
IAC Very Inverse
GE IAC-53
B
Very Inverse (I
2
t)
Refer to BS 142
B1
IEC Very Inverse
Refer to IEC 60255-151 Ed. 1
E3
IEEE Very Inverse
Refer to IEC 60255-151 Ed. 1
E1
CO Extremely Inverse
ABB CO-11
E2
IAC Extremely Inverse
GE IAC-77
C
Extremely Inverse (I
2
t)
Refer to BS 142
C1
IEC Extremely Inverse
Refer to IEC 60255-151 Ed. 1
F1
IEEE Extremely Inverse
Refer to IEC 60255-151 Ed. 1
D
CO Definite Time
ABB CO-6
F
Fixed Time
n/a
46
K Factor
n/a
P
User Programmable
n/a
T1, T2, T3, T4
User Tables
n/a
Time Dial Setting Cross-Reference
Although the time characteristic curve shapes have been optimized for each BE1-11m, time dial settings
of Basler Electric protection systems are not identical to the settings of electromechanical induction disk
overcurrent relays. Table 82-3 helps you convert the time dial settings of induction disk relays to the
equivalent setting for Basler Electric protection systems. Enter time dial settings using BESTCOMSPlus.
For more information, refer to the Inverse Overcurrent (51) Protection chapter.
Using Table 82-3
Cross-reference table values were obtained by inspection of published electromechanical time current
characteristic curves. The time delay for a current of five times tap was entered into the time dial
calculator function for each time dial setting. The equivalent Basler Electric time dial setting was then
entered into the cross-reference table.
If your electromechanical relay time dial setting is between the values provided in the table, it will be
necessary to estimate the correct intermediate value between the electromechanical setting and the
Basler Electric setting.
