Basler BE1-11m User Manual

83-18 9424200996
RTD Module BE1-11m
Analog Inputs
The RTD module contains four programmable analog inputs.
Rating ......................................... 4 to 20 mAdc or 0 to 10 Vdc (user-selectable)
RTD Inputs
The RTD module contains 12 programmable RTD inputs.
User-Selectable Types ............... 100 Ω Platinum (DIN43760), 10 Ω Copper, 100 Ω Nickel, or 120 Ω Nickel
Range ......................................... –50 to 250°C (–58 to 482°F)
Accuracy..................................... ±2°C (3.6°F)
Maximum Lead Length ............... 150 feet (45.72 m) with 22 AWG (0.326 mm
2
) wire
Sensing Current Level ................ 2.5 mA
Isolation ...................................... 35 Vpp
Analog Outputs
The RTD module contains four programmable analog outputs.
Rating ......................................... 4 to 20 mAdc or 0 to 10 Vdc (user-selectable)
Current
Accuracy..................................... ±0.053% of full scale (10 V) at 25°C
Temperature Dependence ......... ±0.029% drift per degree Celsius
Voltage
Accuracy..................................... ±0.055% of full scale (20 mA) at 25°C
Temperature Dependence ......... ±0.04% drift per degree Celsius
Alarm Contact
Type ........................................... Form C (SPDT)
Rating ......................................... 24/48/125/250 Vdc at:
o 30 A make for 0.2 seconds
o 7 A continuous
o 0.3 Adc Break (L/R = 0.04)
Communication Interface
Ethernet
An RTD module with part number 9444100101 is equipped with both fiber and copper Ethernet
connections. An RTD module with part number 9444100100 is equipped with only a copper Ethernet
connection.
Copper Type (RJ45 Connector)
Version ...................................................................... 10BASE-T/100BASE-TX
Maximum Length (One Network Segment) ............... 328 ft (100 m)
Fiber Optic Type (ST Connector)
Version ...................................................................... 100BASE-FX, multimode
Maximum Length (Half-Duplex) ................................ 1,310 ft (399 m)
Maximum Length (Full-Duplex) ................................. 6,600 ft (2,011 m)
Serial
RS-485 19,200 baud
Temperature
Operating Range ........................ –40°C to 70°C (–40°F to 158°F)
Storage Range ........................... –40°C to 70°C (–40°F to 158°F)
