Baumer VCXG - Spectral Sensitivity Details; VCXU Spectral Sensitivity Graphs (2.3 MP); VCXU Spectral Sensitivity Graphs (5.0 MP)

21
400 500 600 700 800 900 1000
0
0.2
0.4
0.6
0.8
1.0
Wave Length [nm]
Relative Response
VCXU-23M
400 500 600 700 800 900 1000
0
0.2
0.4
0.6
0.8
1.0
Wave Length [nm]
Relative Response
VCXU-23C
400 500 600 700 800 900
1000
0
0.2
0.4
0.6
0.8
1.0
Wave Length [nm]
Relative Response
VCXU-50M
400 500 600 700 800 900
1000
0
0.2
0.4
0.6
0.8
1.0
Wave Length [nm]
Relative Response
VCXU-50C
◄Figure5
Spectral sensitivities for
Baumer cameras with
2.3 MP sensor.
◄Figure6
Spectral sensitivities for
Baumer cameras with
5.0 MP sensor.
